Way Wipers

Most of our way wipers have Stainless-Steel-Cases which give them high stability and mechanical loading capacity. The sealing on the backside avoids penetration of coolants. There are no parting lines and glueing problems. The wipers lip material is normally high-quality polyurethane material, for the FBA-V and FBA-E wiper types we use synthetic rubber.

Most types come in standard lengths of 500mm / 19.7 Inch and 1.000 mm /39.4 Inch. All wipers can be made customized to your specification, they are ready to be mounted. No mounting holes are necessary for the readjustement, all screw heads are sinkable The wiper lips are easy to replace.

The wiper lip is made of high-quality material with following features:

• - Excellent mechanical properties
• - High resistance to abrasion
• - Resistance to permanently elevated temperature 90°C /220°F
• - Resistance to short-term elevated temperature 130°C/290°F
• - Restricted resistance to acids, alkaline solutions, benzine
• - Restricted resistance to mineral oil and coolants
• - Excellent resistance against hydrolyze and microorganisms

	Style	Length mm/inches
	A1	560/22.0
	A2	560/22.0 1000/39.4
	A2 Cover	560/22.0
	A2B	560/22.0
	A3	560/22.0
	A4	560/22.0
	A5	560/22.0
	A6	560/22.0 1000/39.4
	A7	560/22.0
	A7B	560/22.0
	A8	560/22.0
	A9	560/22.0
	A10	560/22.0
	A11	560/22.0
	A12	560/22.0
	A13	560/22.0
	A14	560/22.0
	A15	560/22.0
	A17	560/22.0
	N1	560/22.0
	N2	560/22.0
	N3	560/22.0

	OTHER IMPORTANT FEATURES

MEASURING	CUTTING
PINNING	MOUNTING
